Product Details:
Payment & Shipping Terms:
|
| Type: | RO Membrane Element | Model NO.: | 3013-1000 BW |
|---|---|---|---|
| Salt Rejection Rate: | 95% | Capacity: | 1000GPD |
| Warranty: | 2 Years | Weight: | 0.62KG |
| Working Up: | 1500TDS | Recovery: | 50% |
| Function: | Water Purification Plant | Applicable Industries: | Hotels, Garment Shops, Manufacturing Plant, Food & Beve |
| Highlight: | high flow reverse osmosis membrane,reverse osmosis membranes for water treatment,reverse osmosis 1000 gpd |
||
Commercial High Flow 3313-1000GPD Reverse Osmosis RO Membrane for Water Treatment
Due to the influence of water quality and other factors, the specific replacement time depends on whether the daily maintenance and cleaning of the reverse osmosis membrane are timely, and the water quality will determine how long the membrane can be used. With the continuous development of industry, the phenomenon of water pollution is becoming more and more serious, which has caused great harm to people's survival. More and more industrial production and domestic water manufacturers choose to use industrial pure water equipment to improve water quality. In the process of water equipment, due to water impurities, it will slowly accumulate on the surface of the reverse osmosis membrane, which will affect the use of the equipment for a long time.
If you need filtered water, a reverse osmosis system is a good solution. Install a reverse osmosis system under your kitchen sink to supply purified water. You can do it yourself in less than 2 hours.
RO system membrane is made of the sedi-permeable membrane with the 0.1mm filtration precision for separating and removing the dissolved solids, organics, bacteria etc. According to the water output capacity, the different large flow membrane is available as follows: 300G, 400G,500G,600G,700G,800G,1000G.
Performance and test conditions
| model | Stable rejection rate(%) | average permeate flowGPD(m3/d) | test condition | ||
| operation pressure psi(Mpa) | test liquid NaCl(ppm) | recovery rate (%) | |||
| 3012-300 | 97 | 300(1.14) | 90(0.61) | 500 | 50 |
| 3013-400 | 95 | 400(1.52) | 90(0.61) | 500 | 50 |
| 3013-600 | 95 | 600(2.28) | 100(0.7) | 500 | 50 |
| 3013-800 | 95 | 800(3.04) | 100(0.7) | 500 | 50 |
| 3313-1000 | 95 | 1000(3.79) | 100(0.7) | 500 | 50 |
Note: Single membrane permeate flow change in the range of ±15%
Test Conditions
Test Pressure 100psi( 0.7Mpa)
Temperature 25ºC
Concentration of Testing Solution (NaCl) 500ppm
Testing Solution PH 2-11
Note:
1. The Max. continous operation temperature is 35ºC when PH rate over 10.
2. In certain conditions,if would cause membrane breakage if the free chlorine or the other oxidant in feedwater.The production quality guarantee range is notincluded membrane breakage by oxiadation.
Dimension of Membrane Element
3013-1000: A:13.0inch B:3.0inch C:0.68inch D:0.75inch E:11.5inch
High-flow, high-rejection, low-energy reverse osmosis (RO) membrane elements are making desalination a more economical choice than ever before by reducing the cost of produ-cing potable water by up to 20%.
FAQ:
