| Type: | Reverse Osmosis Membrane | Model NO.: | BW-3012-300 |
|---|---|---|---|
| Desalination: | 97% | Capacity: | 300GPD |
| Certification: | CE, RoHS, ISO9001, NSF | Warranty: | 1 Year |
| Test Solution: | 500ppm | Operation Pressure: | 90psi |
| Highlight: | 300 Gpd Domestic Ro Membrane,Home Ro Membrane,300 gpd ro |
||
3012-300 Gpd RO Membrane for Domestic Water Filter Replace Water Treatment
This standard specifies product specifications for reverse osmosis membrane elements for household and similar purposes (here in after referred to as reverse osmosis elements) .This standard applicable to reverse osmosis membrane elements that use municipal tap water or centralized water supply as raw water for use in homes and similar places.
Performance
| model | Stable rejection rate(%) | average permeate flowGPD(m3/d) | test condition | ||
| operation pressure psi(Mpa) | test liquid NaCl(ppm) | recovery rate (%) | |||
| 1812-BW50 | 97 | 50(0.19) | 60(0.41) | 250 | 15 |
| 1812-BW75 | 97 | 75(0.28) | 60(0.41) | 250 | 15 |
| 1812-BW100 | 97 | 100(0.38) | 60(0.41) | 250 | 15 |
| 2012-150 | 95 | 150(0.57) | 70(0.5) | 500 | 15 |
| 2012-200 | 95 | 200(0.76) | 70(0.5) | 500 | 15 |
| 3012-300 | 97 | 300(1.14) | 90(0.61) | 500 | 15 |
Membrane Dimention
3012-300: A:12.0mm B:3.0mm C:0.68mm D:0.75mm E:10.0mm
1.When PH is above 10, the Maximum Temperature of Continuous Operation is 35ºC.
2. Under certain conditions, the presence of free chlorine and other oxidants in the water may cause serious membrane damage, which doesn't belong to product warranty range.
Domestic RO membrane elements are spiral wound, composite polyamide membrane elements for Tap Water and Well Water treatment in low salinity application. These membranes are characterized by a very low operating feed pressure, normally is from 65psi(0.45MPa) and result in higher salt rejection rate, above 96%. These membranes are designed for domestic/commercial water treatment applications, such as the treatment of low salinity waters for home, residence, hospital, laboratory, shop, store,......
